Hardware photos
DEC LK411-AA keyboard
2025-03-19
DEC LK411-AA keyboard
I have several of these keyboards!
DEC VT510 - DECserver 100
2011-03-01
DEC VT510 - DECserver 100
Connected to port 0 on the DECserver. I've since fixed the display - bad VGA cable.
DEC VT510 - FreeBSD
2011-03-01
DEC VT510 - FreeBSD
Configured as a serial console.
DEC VT510 - LAT session
2025-03-10
DEC VT510 - LAT session
LAT session from the DECserver 100 to a FreeBSD box.
DEC VT510 - Microsot Word
2011-03-01
DEC VT510 - Microsot Word
Microsoft Word running on SCO Unix
DEC VT510 - old prompt
2011-03-01
DEC VT510 - old prompt
I wish I still had this profile
DEC VT510 - screen capture
DEC VT510 - screen capture
Testing a VGA capture device with the terminal.
DEC VT510 terminal
2025-03-17
DEC VT510 terminal
Amber Character-mode single session terminal. Could use a standard PC keyboard.
DEC VT525 terminal
2025-03-17
DEC VT525 terminal
Character-mode multi-session terminal.
DECserver 100 (front)
2025-03-17
DECserver 100 (front)
LAT terminal server with 8 DB25 RS-232 ports.
DECserver 100 (rear)
2025-03-17
DECserver 100 (rear)
LAT terminal server with 8 DB25 RS-232 ports.
Epson unknown LS_2170? (front)
2025-03-20
Epson unknown LS_2170? (front)
Unknown engineering sample.
Epson unknown LS_2170? (rear)
2025-03-20
Epson unknown LS_2170? (rear)
Unknown engineering sample.
Honeywell BTRM125C logic board
2025-03-27
Honeywell BTRM125C logic board
Provides three extra DB25 ports.
Honeywell BTRM125C logic board (edge)
2025-03-27
Honeywell BTRM125C logic board (edge)
Provides three extra DB25 ports.
Honeywell BTRM125C main board ROMS
2025-03-27
Honeywell BTRM125C main board ROMS
I think these are all on Bitsavers.
Honeywell BTRM125C mainboard (first half)
2025-03-27
Honeywell BTRM125C mainboard (first half)
Main logic board. Spot the MC68000!
Honeywell BTRM125C mainboard (second half)
2025-03-27
Honeywell BTRM125C mainboard (second half)
Main logic board.
Honeywell BTRM125C terminal (front)
2025-03-26
Honeywell BTRM125C terminal (front)
A block mode asynchronous terminal.
Honeywell BTRM125C terminal (rear, DIPs)
2025-03-26
Honeywell BTRM125C terminal (rear, DIPs)
A block mode asynchronous terminal.
Honeywell BTRM125C terminal keyboard
2025-03-26
Honeywell BTRM125C terminal keyboard
A Hall effect keyboard, lovely!
HP 700/98 running TSM
2025-03-13
HP 700/98 running TSM
Terminal Session Manager on HP-UX.
HP 700/98 terminal
2025-03-17
HP 700/98 terminal
I left my purple LED lights on!
HP 700/98 terminal
2025-03-19
HP 700/98 terminal
The worst keyboard ever?
Keychron V1B2 keyboard
2025-01-29
Keychron V1B2 keyboard
Really nice keyboard.
Wyse WY-60 terminal
2025-03-22
Wyse WY-60 terminal
A character-mode single-session terminal.
Wyse WY-60 terminal keyboard
2025-03-22
Wyse WY-60 terminal keyboard
Not bad as keyboards go, I prefer the LK411 though!
